MVT ARCTIC SERIES Air/air system in multi-split design for heating and cooling

The efficient heat pump solution for several rooms at once

The MVT-ARCTIC series is a modulating air/air heat pump that lets you operate up to 5 indoor units at once. In the process, you can combine wall-mounted units, ceiling cassettes, and now even compact wall chests to suit your needs. Efficient heating operation down to -20°C can be realised with this series. The standard built-in cooling function ensures a pleasant room climate in summer.

Up to 5 rooms can be cooled
Microprocessor-controlled unit technology
Coolant injection by electronic expansion valves
Outdoor units are filled with R32 refrigerant at the factory (line length up to 5 m)
Standard winter fan speed control for cooling and heating operation down to -20 °C
Automatic adjustment of the airflow in cooling and heating mode
Programmable 24-hour timer function
With infrared remote control in the standard version
Alarm contact (MXD, MXT and ATY Deko series)
Contact for external activation and deactivation (MXW, MXD, MXT and ATY Deko series)
Connection option REMKO Smart-Control Touch (MXW, MXD, MXT and ATY Deko series)
Wi-Fi connectivity optionally available (MXW, MXD, MXT, ATY and ATY Deko series)

Technical data

Variant	MVT 603 ARCTIC	MVT 903 ARCTIC	MVT 1053 ARCTIC	MVT 1403 ARCTIC
Cooling capacity	5.3 (2.1-6.9) kW	7.9 (2.9-8.5) kW	10.5 (2.1-10.6) kW	12.3 (2.1-14.2) kW
Energy efficiency rating for cooling	A++	A++	A++	A++
Energy efficiency ratio SEER	6.1	6.1	6.5	6.1
Power consumption annual, cooling, QCE	304 kW/h	453 kW/h	565 kW/h	652 kW/h
Heating capacity	5.6 (2.3-7.2) kW	8.2 (2.0-8.5) kW	10.6 (2.3-11.1) kW	12.3 (2.3-14.8) kW
